Equipment Rentals / Infiled XII Series 1.9
Infiled XII Series 1.9
Description
Boost your creativity with the INFiLED XII Series 1.9! Let your imagination light up the possibilities and transform your next event with a custom designed LED wall that scales to any size and shape.
Request a RentalProduct Details
- Seamless, concave, and convex curves up to ±30°.
- Custom curve capability at every 5° with seven position adjustments.
- Wide horizontal and vertical viewing angles up to 160° for enhanced visual performance and color uniformity.
Technical Specifications
| Pixel Pitch | 1.95mm |
| Physical Density | 262,144 pixels/meters (squared) |
| LED Arrangement | 3 IN 1 SMD |
| Module Dimensions | 500x125mm |
| Module Resolution | 256×64 pixels |
| Cabinet Size | 500x500x76mm |
| Cabinet Resolution | 256×256 pixels |
| Cabinet Weight | 17.5 lbs |
| Max Power Consumption | 480 w/meter (squared) |
| Average Power Consumption | 160 w/meter (squared) |
| Viewing Angle (H x V) | 160°/160° |
| Power Source | 100-240V AC 50-60Hz |
| Operating Temperature | -10°C~+45°C |
| Refresh Rate | < 3,840Hz |
| IP Rating | IP30 |
| Signal Output Source | DVI, HDMI, DP, MINI DP, VGA, SDI, HD SDI |
| Verification | CE, FCC, ETL, ROHS, REACH, WEEE in processing |
