Meyer Sound designed the MM‑4XP self-powered miniature loudspeaker (with IntelligentDC technology) for high-quality distributed systems. Housed in a compact aluminum enclosure, the MM‑4XP is especially suitable for installations involving space limitations and visibility concerns, such as fill and spot coverage, and hidden locations like chancel steps in houses of worship. Its flexible and easy-to-configure mounting options, as well as its ability to effortlessly reproduce both speech and music, make it an excellent choice for fixed applications, theatrical presentations (stage lip frontfill), and small portable systems for corporate AV.
Extremely compact enclosure
Wide-range frequency response
Effortless reproduction of both speech and music
Exceptional SPL to size ratio
Support for long cable runs with light-gauge cables
|Operating Frequency Range||120 Hz – 18 kHz|
|Frequency Response||135 Hz – 17 kHz ±4 dB|
|Phase Response||400 Hz – 20 kHz ±45°|
|Linear Peak SPL||111.5 dB with crest factor >16.5 dB (M-noise), 109 dB (Pink noise), 111 dB (B-noise)|
|Horizontal Coverage||80° (3 kHz – 14 kHz ±10°); 120° (below 2 kHz)|
|Vertical Coverage||80° (3 kHz – 14 kHz ±10°); 120° (below 2 kHz)|
|Total Output Power||440 W peak|
|Connector||SwitchCraft EN3 5-pin male (two pins for 48 V DC power, three pins for balanced audio)|
|Safety Agency Rated Voltage||48 V DC|
